Anti-Ankyrin-G Antibody (N106/20)

Catalog #:   RHG35101 Specific References (27) DATASHEET
Host species: Mouse
Isotype: IgG2a, kappa
Applications: IB, ICC, IF
Overview

Catalog No.

RHG35101

Species reactivity

Human, Mouse, Rat

Host species

Mouse

Isotype

IgG2a, kappa

Clonality

Monoclonal

Target

Ankyrin-3, ANK3, ANK-3, Ankyrin-G

Concentration

1 mg/ml

Endotoxin level

Please contact with the lab for this information.

Purity

>95% as determined by SDS-PAGE.

Purification

Protein A/G purified from cell culture supernatant.

Applications

IB, ICC, IF

Form

Liquid

Storage buffer

0.01M PBS, pH 7.4.

Stability and Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles. Store at 4°C short term (1-2 weeks). Store at -20°C 12 months. Store at -80°C long term.

Clone ID

N106/20

Data Image
  • Immunocytochemistry/Immunofluorescence
    Immunocytochemistry/Immunofluorescence analysis using Mouse Anti-Ankyrin G Monoclonal Antibody, Clone N106/20 (RHG35101). Tissue: Neuroblastoma cells (SH-SY5Y). Species: Human. Fixation: 4% PFA for 15 min. Primary Antibody: Mouse Anti-Ankyrin G Monoclonal Antibody (RHG35101) at 1:100 for overnight at 4°C with slow rocking. Secondary Antibody: AlexaFluor 488 at 1:1000 for 1 hour at RT. Counterstain: Phalloidin-iFluor 647 (red) F-Actin stain; Hoechst (blue) nuclear stain at 1:800, 1.6mM for 20 min at RT. (A) Hoechst (blue) nuclear stain. (B) Phalloidin-iFluor 647 (red) F-Actin stain. (C) Ankyrin G Antibody (D) Composite.
  • Immunocytochemistry/Immunofluorescence
    Immunocytochemistry/Immunofluorescence analysis using Mouse Anti-Ankyrin G Monoclonal Antibody, Clone N106/20 (RHG35101). Tissue: Neuroblastoma cell line (SK-N-BE). Species: Human. Fixation: 4% Formaldehyde for 15 min at RT. Primary Antibody: Mouse Anti-Ankyrin G Monoclonal Antibody (RHG35101) at 1:100 for 60 min at RT. Secondary Antibody: Goat Anti-Mouse ATTO 488 at 1:200 for 60 min at RT. Counterstain: Phalloidin Texas Red F-Actin stain; DAPI (blue) nuclear stain at 1:1000, 1:5000 for 60 min at RT, 5 min at RT. Localization: Cytoplasm . Magnification: 60X. (A) DAPI (blue) nuclear stain. (B) Phalloidin Texas Red F-Actin stain. (C) Ankyrin G Antibody. (D) Composite.
References

Reduced expression of Ankyrin-G and E-cadherin in duodenal mucosal biopsy of subjects with celiac disease., PMID:38324966

Complement-membrane regulatory proteins are absent from the nodes of Ranvier in the peripheral nervous system., PMID:37875972

Microglial synaptic pruning on axon initial segment spines of dentate granule cells: Sexually dimorphic effects of early-life stress and consequences for adult fear response., PMID:33890333

Dynamic Regulation of Synaptopodin and the Axon Initial Segment in Retinal Ganglion Cells During Postnatal Development., PMID:31417359

A constitutively-active IKK-complex at the axon initial segment., PMID:29079505

Aging Does Not Affect Axon Initial Segment Structure and Somatic Localization of Tau Protein in Hippocampal Neurons of Fischer 344 Rats., PMID:28785724

CK2-regulated schwannomin-interacting protein IQCJ-SCHIP-1 association with AnkG contributes to the maintenance of the axon initial segment., PMID:25950943

Striatins as plaque molecules of zonulae adhaerentes in simple epithelia, of tessellate junctions in stratified epithelia, of cardiac composite junctions and of various size classes of lateral adherens junctions in cultures of epithelia- and carcinoma-derived cells., PMID:25501894

CK2 accumulation at the axon initial segment depends on sodium channel Nav1., PMID:25109776

A unique ion channel clustering domain on the axon initial segment of mammalian neurons., PMID:24477962

Ankyrin-B structurally defines terminal microdomains of peripheral somatosensory axons., PMID:22886464

Active vaccination with ankyrin G reduces β-amyloid pathology in APP transgenic mice., PMID:22688190

Anti-GD1a antibodies activate complement and calpain to injure distal motor nodes of Ranvier in mice., PMID:20513658

Heat opens axon initial segment sodium channels: a febrile seizure mechanism?, PMID:19743470

Polarized distribution of ion channels within microdomains of the axon initial segment., PMID:17111377

A common ankyrin-G-based mechanism retains KCNQ and NaV channels at electrically active domains of the axon., PMID:16525039

Expression of Nav1.6 sodium channels by Schwann cells at neuromuscular junctions: role in the motor endplate disease phenotype., PMID:16078241

Elevated ankyrin G in a plexiform neurofibroma and neuromas associated with pain., PMID:15519868

AMPA/kainate receptors in mouse spinal cord cell-specific display of receptor subunits by oligodendrocytes and astrocytes and at the nodes of Ranvier., PMID:12594733

Interaction of the Nav1.2a subunit of the voltage-dependent sodium channel with nodal ankyrinG. In vitro mapping of the interacting domains and association in synaptosomes., PMID:12036953

Structural requirements for interaction of sodium channel beta 1 subunits with ankyrin., PMID:11997395

Ankyrin G and voltage gated sodium channels colocalize in human neuroma--key proteins of membrane remodeling after axonal injury., PMID:11950515

Identification of Ank(G107), a muscle-specific ankyrin-G isoform., PMID:11796721

betaIV spectrin, a new spectrin localized at axon initial segments and nodes of ranvier in the central and peripheral nervous system., PMID:11086001

Expression of sodium channel SNS/PN3 and ankyrin(G) mRNAs in the trigeminal ganglion after inferior alveolar nerve injury in the rat., PMID:10915577

Clustering of neuronal sodium channels requires contact with myelinating Schwann cells., PMID:10739572

Isoforms of ankyrin-3 that lack the NH2-terminal repeats associate with mouse macrophage lysosomes., PMID:9060470

Datasheet
$ 328
Product specifications
100 μg 328 1 mg 1640
